Product Description:
Model No.:
0021074 (CV-16)
Shell
Color: White
Channel/Button:
16
Button
Symbol: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12,13,14,15,16
Operating
Voltage: 12V (1
x 23A -12V battery, can be used for 12 months)
Operating
Current: 15mA
Operating
Frequency: 433Mhz
Encoding
Chip: PT2262/PT2264/SC2262
Encoding
Type: Fixed
code by soldering, up to 6561 codes
Transmitting
Distance: 500m / 1500ft (theoretically)
The
distance of 500m is a theoretical data, it shall be operated in an open ground,
no barriers, no any interference. But in the practice, it will be hindered by
trees, walls or other constructions, and will be exposed to some interference
by other signals. Therefore, the actual distance may or may not reach 500m.
If
you stretches the telescopic antenna, it can have a further working range,
which is twice as much as it used to be.
Modulation
Mode: ASK
Operating
Temperature: -20 ° C to +70 ° C
Unit Size: 110mm
x 50mm x 18mm
Uses:
garage doors, motorcycles, car alarm products, home security products, wireless
remote control products, industrial control products.
