The DC
motor is a machine that transforms electric energy into mechanical energy in
form of rotation. It can rotate forward or reverse, and you can exchange DC
motor's two wires to change the rotating direction of motor.
Application:
Mainly used for remote-controlled car, toy car, miniature DC pump, electric motorbike,
ATV, Kart, robot, rolling blind and electric projector etc.
Feature:
Gearhead motor
High quality
With metal cover
Built-in cooling fan
Heavy duty design
Runs in either direction by reversing power supply polarity
Benefiting from high torque and low noise, this motor is solidly constructed and
ready to install in numerous applications.
Specifications:
Nominal voltage: 6V DC
Operating voltage range: 3 - 9V DC
Diameter: 25mm
Length (excluding shaft): 57.8mm
Total length: 73.3mm
Shaft length: 11.5mm
Shaft diameter: 4mm
Front panel 3.0mm Screw for fixing this motor
Optional no-load speed at 6V: 12RPM, 26RPM, 58RPM, 133RPM, 281RPM, 646RPM, 1363RPM.
No-load speed at 6V
12 RPM
26 RPM
58 RPM
133 RPM
281 RPM
646 RPM
1363 RPM
No-load current (MA)
60
60
60
60
60
60
60
Load speed (RPM)
10
20
46
113
238
516
1090
Load current (MA)
280
280
300
300
300
300
300
Operating torque (kg.cm)
10
5
3
1.1
0.5
0.23
0.1
Stall torque (kg.cm)
Banned
35
15
6
4
1.5
0.8
Stall current (MA)
900
900
900
900
900
900
900
Gear ratio
1:500
1:226
1:103
1:45
1:21.3
1:9.28
1:4.4
