3 Buttons RF Wireless Wall Mounted Switch Control Electric Devices On/Off

Manual

Product Description:

• Model No.: 0021082 (HR-3)
• Wall Mounted Switch
• Shell Color: White
• Channel/Button: 3
• Button Symbol: no symbol
• Operating Voltage: 12V (1 x 27A -12V battery, can be used for 12 months)
• Operating Current: 4mA
• Operating Frequency: 433Mhz
• Encoding Chip: EV1527
• Encoding Type: Learning code (up to 1 million codes, reducing code collision and unauthorized code scanning possibilities.)
• Transmitting Distance: 50m / 150ft (theoretically)
• The distance of 50m is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be exposed to some interference by other signals. Therefore, the actual distance may or may not reach 50m.
• Modulation Mode: ASK
• Operating Temperature: -20 ° C to +70 ° C
• Unit Size: 86mm x 86mm x 16mm
• Weight: 90g
• No wires, simply affix the remote control to any place you want by double faced adhesive tape.
• This transmitter can work with different kinds of receivers, include model 0020360 (S1UB-DC12), 0020361 (S1UB-AC220), 0020363 (S1PUB-DC12), 0020365 (S1PUB-AC220), 0020492 (S1XB-DC12), 0020457 (S1XB-AC220), 0020610 (S1RU-DC12), 0020612 (S1XC-AC220), etc.

Uses: garage doors, motorcycles, car alarm products, home security products, wireless remote control products, industrial control products.
