8 Channels -103dBm 9-12V Wireless Remote Radio Transmitter Module TB-06

 Manual

Feature:

• Model No.: 0021109 (TB-06)
• Size: 50mm x 36mm x 5mm
• Working Voltage: DC9~12V (battery is not included)
• Working Current: 20mA
• RF Sensitivity: -103dBm
• Transmitting Distance: 50m /150ft (in open field)
• Modulation Method: Amplitude modulation (ASK or OOK)
• Encoding Mode: Fixed code by Soldering
• Working Temperature: -20°C ~ +70°C
• Frequency: 433.92 MHz
• Oscillation resistor / Timing resistor: We can offer 1.2M, 1.5M, 1.8M, 2.2M, 3.3M or 4.7M, you can choose one.
• Reliable Control: Use an 8-bit code (Encoding).
• Stable performance; using SAW (surface acoustic wave) to stabilize frequency
• Wide working voltage range, large transmitting power and long transmission distance

Application:

• Used for wireless calling system, burglar alarm, wireless data transmission, auto data collection system and so on.
• Applied to all fixed code receivers with 1, 2, 3, 4, 6, 8, 10, 12, 15 channels

Notes: The transmitting frequency, encoding mode and timing resister should be compatible with the receiver.
