Digital Screen DC 12V~80V 30A Motor Speed Adjust Governor

Price: US $45.00

Model: 0044004 (DC 12V-80V 30A)

Please Choose:

Qty:

Feature:
Model: 0044004
Working Voltage: DC 12V~80V
Rated current: 30A
Size of controller: 112 x 78 x 36 mm
Size of screen: 80 x 43 x 26 mm
With 30A fuse
Speed Adjustment Range: 0%~100%.
Adjustable potentiometer: 100K
The speed of motor can be adjusted through twisting the knob, and the screen will display digital 0~100. A larger number corresponds to a faster speed.

Connection:
1) Connect DC power supply to the input terminals.
2) Connect motor to the output terminals.

Operation with motor:
Twist the knob to adjust the rotation speed of motor.
Twist clockwise, the rotation speed of motor will speed up.
Twist anti-clockwise, the rotation speed of motor will slow down.
