Product Description:
Model No.: CB-2V-AC
With Extended Trigger Wires
Triggering method: AC power100~240V input
Shell Color: Grey
Channel/Button: 2
Button Symbol: no symbol Operating Voltage: 9V (1 x 6F22-9V battery, 9V
Ordinary battery can be used for a week, 9V Rechargeable Lithium Battery can be
used for two weeks, if you want a longer working time, please use a 9V power
adapter.)
Operating Current: 30mA
Operating Frequency: 315 MHz
Encoding Chip: PT2262 / PT2264 / SC2262
Encoding Type: Fixed
code by soldering, up to 6561 codes
Transmitting Distance: 1000m / 3000ft (theoretically) It has an on / off button on the side.
Modulation Mode: ASK
Operating Temperature: -20 ° C to +70 ° C
Unit Size: 100mm x 68mm x 50mm
Uses: garage doors, motorcycles, car alarm products, home security products,
wireless remote control products, industrial control products. External Telescopic Antenna:
Length of external telescopic antenna: 108mm / 445mm (stretch)
With SMA connector.
If you stretches the external telescopic antenna, it can have a further working
range. Controlling
the device by pressing buttons on the transmitter:
Press button A on the transmitter -> On, the receiver starts to work;
Press button B on the transmitter -> Off, the receiver stops working. Controlling
the device by inputting or no inputting AC100~240V power to red wire and black
wire of the transmitter:
When it hasAC100~240V power input for red wire and black wire of the
transmitter, the transmitter will be triggered and then it will send an RF
signal of "ON", the receiver will starts to work.
When it does not have AC100~240V power input for red wire and black wire of the
transmitter, the transmitter will be triggered and then it will send an RF
signal of "OFF", the receiver will stops working. Add Receiver:
This transmitter can remote control different receivers, including :
