Feature: Application: It can be used in industry automation, agriculture automation and home automation, such as factory, house, farm, pasture, vehicle, ship, offshore operation, aerial vehicle, field call, etc. It can remote control equipments on land, water and air, such as remote control lights, sirens, locks, motors, fans, winches, blinds, linear actuators, doors, windows, electric solenoid valves, security alarm, business signs and various devices. Wireless control, easy to install. AC Power Output: It can control AC 380V equipment You can turn on/ off the receiver with transmitter (remote control) from any place within a reliable distance. Wireless RF signal can pass through walls, floors, doors or windows. With reverse power protection and over current protection. One/several transmitters can control one/several receivers simultaneously. You can use two or more units in the same place. Lack-phase protection: To prevent equipment burned down Receiver Parameters: Model No.: S1UA-AC380-ANT3 Channel: 1 CH Power Supply (Operating Voltage): AC380V Output: AC380V Working Frequency: 433MHz Control Modes: Interlocking Static Current: ≤6mA Maximum Working Current: 32A, 380V/7.5KW Case size: 200mm x 135mm x 120mm Work with Fixed code transmitters Transmitters Parameters:
Model No.: 0021011 (CP-2)
Shell Color: White
Channel/Button: 2
Button Symbol: big button, small button
Operating Voltage: 12V (1 x 23A -12V battery, can be used for 12 months)
Operating Current: 8mA
Operating Frequency: 433Mhz
Encoding Chip: PT2262/ PT2264/ SC2262
Encoding Type: Fixed code by soldering, up to 6561 codes
Transmitting Distance: 500m / 1500ft (theoretically)
Modulation Mode: ASK
Operating Temperature: -20 ° C to +70 ° C
Unit Size: 85mm x 36mm x 16mm
Matching Transmitters: The receiver can work with different transmitters, such as model CG-2 (500M), CV-2 (500M), CB-2 (1000M) etc. Working Range: With a transmitter (such as CP-2) to form a complete set, the maximum working distance can reach 500M in an open ground. The maximum working distance is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be interfered by other wireless signals. Therefore, the actual distance may not reach this maximum working distance. If you want to have a further working range, you can install an external antenna to the receiver, and you also can use a powerful transmitter, such as CB series transmitters. Telescopic Antenna: Length of external telescopic antenna: 108mm / 445mm (stretch) If you stretches the external telescopic antenna, it can have a further working range. Usage (with the transmitter CP-2): The receiver can be used to control AC 380V pumps, motors and other equipments. Wiring: Connect three lines of the AC380 power supply to terminal “L1”, “L2” and “L3”; Connect three lines of the AC 380V equipment to terminal “T1”, “T2” and “T3” 1) Press
the big button of the transmitter, receiver outputs AC 380V power, the 380V equipment works. 2) Press
the small button of the transmitter, receiver stops to output AC 380V power, the 380V equipment stops to work. Manual button: 1) Press button
ON of the receiver, receiver outputs AC 380V power, the 380V equipment works. 2) Press button
OFF of the receiver, receiver stops to output AC 380V power, the 380V equipment stops to work.
